International HV SERIES 607
- Heavy duty, double-sided galvanized steel cab for long-term durability
- Wide-track axles providing maximum maneuverability and up to a 50-degree wheel cut
- New door, side glass and mirror designs improve lateral visibility and workplace safety
- All-new dash designed for the driver with more space for additional rocker switches
- Available premium gauge cluster designed with driver input is customizable with virtual gauges
- Best-in-class Diamond Logic® electrical system with new industry-standard J1939 architecture
- Easy-access column-mounted shifter integrated with engine braking helps keep hands on the wheel
- All-new HVAC system designed for reliability, now includes a high-performance MAX defrost feature HV607
- .5" thick super single frame rail rated up to 3.35M RBM
Application
- Municipal Plow
- Construction Dump
- Bridge Formula Applications
- 4x4 Fire & Emergency
Detailed Specifications
View the detailed specifications for the HV Series
or download the spec sheet.
GVW
- 51,000 – lbs. (4x2)
- 68,000 – lbs. (6x4)
Models/BBC/BA
- 107"BBC / 40.3" BA
Wheelbase Options
- 136 - 340" Axle
Configurations
- 4x2
- 6x4
Rear Axle
- SINGLE REAR AXLE (4x2)
- Meritor - Single Reduction: 17,000 – 30,000 lbs. - Double Reduction: 26,000 – 38,000* lbs. - Two-Speed: 21,000 – 23,000 lbs
- Dana - Single Reduction: 17,500 – 31,000 lbs. - Two-Speed: 19,000 – 23,000* lbs.
- TANDEM REAR AXLE (6x4)
- Meritor: - Single Reduction: 34,000 – 46,000 lbs.
- Dana Spicer: - Single Reduction: 46,000 lbs.
Front Axle
- Dana Spicer - Non-Driving: 10,000 – 20,000 lbs
- Meritor - Non-Driving: 10,000 – 22,000 lbs.
Frames
- Heat Treated Alloy Steel 120,000 PSI
- 11.25" x .5" thick super single rail
Front Suspension
- Spring Multileaf: 14,000 – 20,000 lbs.
- Parabolic Taperleaf: 10,000 – 22,000 lbs.
Rear Suspension
- Chalmers: 23,000 – 46,000 lbs.
- Hendrickson
- RT: 34,000 – 46,000 lbs.
- HAS: 40,000 – 46,000 lbs.
- HMX: 40,000 – 46,000 lbs.
- PRIMAAX: 23,000 – 46,000 lbs.
- Link: 46,000 lbs.
Electrical System
- ALTERNATORS
- Bosch: 12 Volt, 160 – 200 Amp • Leece-Neville: 12 Volt, 160 – 325 Amp • Delco Remy: 12 Volt, 165 – 240 Amp
- BATTERY SYSTEMS
- JCI: 12 Volt 1400 – 2100 CCA • Fleetrite®: 12 Volt 1320 – 3800 CCA • Deka: 12 Volt 2775 CCA
Exhaust System
- Single canister after-treatment device
- Frame Mounted Right Side, Back of Cab
- Short Horizontal Tailpipe
Brakes
- Air Drum Brakes with ABS, Optional Traction Control, Optional Electronic Stability Program with Traction Control
- Air Disc Brakes
Power Steering
- Single Power
- Dual Power on Front Axle 16,000 lbs. and Above
Engines
- Cummins® B6.7: Up to 360** hp, 800 lb.-ft. of torque
- Cummins® L9: Up to 450** hp, 1250 lb. –ft of torque
Transmissions
- Eaton® Fuller: 6-, 10-, 13-Speed Manual
- Eaton UltraShift+®: 10- & 11-Speed Automated Manual
- Eaton Fuller Advantage™ Series: 10-speed Automated Manual
- Allison: 2000, 3000 Series (HS, EVS, RDS) Automatic
Fuel Tanks
- 40 – 120 Gallons, Single or Dual, NonPolished or Polished Aluminum, Mounted Right or Left Side Under Cab
Tires
- Continental
- Michelin
- Goodyear
- Bridgestone
